Description
Cold Chamber
2017
Japan
Toshiba
350 Tons
105
China
SPECIFICATIONS
Table
SPECIFICATIONS
the machinary is overhauled in very good condition available to sell including / excluding the related peripheral as per the customer request.
Table
TOSHIBA 350 TON | |
Type of machinery | Cold Chamber Die Casting Machine |
Degree of newness | more than 90% |
|
|
Equipment data |
|
locking force (KN) | 3500 |
space between tie bars (mm) | 650×650 |
die height(min-max) (mm) | 300-700 |
injection weight (KG) | 1.9-3.3 |
ejection force (KN) | 190 |
ejection stroke(mm) | 90 |
machine weight | 11.9 |
machine dimension (LXWXH) | 5745x1830x313 |
|
|
Japanese Toshiba 350ton including ladle,sprayer,extractor | |
